Coil nails · Coil nails family
15° Wire-Collated Coil Nails
15° wire-collated coil nails. Catalogue dimensions and finish options are shown below; exact supply and suitability require confirmation.
- Length
- 2 in · 50.8 mm, 2½ in · 63.5 mm, 3 in · 76.2 mm
- Diameter
- 2.3 mm, 2.5 mm, 2.8 mm
- Finish options
- Bright, Electro-galvanized, Hot-dip galvanized
Catalogue reference · exact configuration, packing and supply to confirm.
Coil nails, in detail.
Catalogue reference
Supplier catalogue p.27: XJPC-05, XJPC-07 and XJPC-09. The three variation rows retain their original catalogue dimensions.
Requested finish, shank, packing and current supply require confirmation. No model-specific pairing, outdoor durability or structural performance is established by this page.
Selection and purchasing references
Return to this product family · Specification checks · Purchasing notes. These references do not establish model compatibility.
Range summary
Catalogue source & review notes
Specifications are copied from the supplier product catalogue. Dimensions are catalogue values, not newly certified measurements; packing, certification and current supply require confirmation.
Product specifications
| Length | 2 in · 50.8 mm, 2½ in · 63.5 mm, 3 in · 76.2 mm |
|---|---|
| Diameter | 2.3 mm, 2.5 mm, 2.8 mm |
| Finish options | Bright, Electro-galvanized, Hot-dip galvanized |
| Collation | 15° wire coil |
| Shank options | Ring, Screw, Smooth |
| Head / point | Round head / diamond point |
Catalogue references
| Reference | Length | Diameter |
|---|---|---|
| XJPC-05 | 2 in · 50.8 mm | 2.3 mm |
| XJPC-07 | 2½ in · 63.5 mm | 2.5 mm |
| XJPC-09 | 3 in · 76.2 mm | 2.8 mm |
Product documents
Approved downloadable documents will appear here.
